COMBINE CYCLES POWER PLANTS (CCPP)

A combined-cycle power plant uses both a gas and a steam turbine together to produce up to 50% more electricity from the same fuel than a traditional simple-cycle plant. The waste heat from the gas turbine is routed to the nearby steam turbine, which generates extra power.

1. Gas turbine burns fuel:
   The gas turbine compresses air and mixes it with fuel that is heated to a very high temperature. The hot air-fuel mixture moves through the gas turbine blades, making them spin.
   The fast-spinning turbine drives a generator that converts a portion of the spinning energy into electricity.
2. Heat recovery system captures exhaust:
   A heat recovery steam generator (HRSG) captures exhaust heat from the gas turbine that would otherwise escape through the exhaust stack.
   The HRSG creates steam from the gas turbine exhaust heat and delivers it to the steam turbine.
3. Steam turbine delivers additional electricity:
   The steam turbine sends its energy to the generator drive shaft, where it is converted into additional electricity.

KemalPasa-2005, 120MWeCCPP, Turkey

2 x GTG GE F6C (new!!!) –41MWe, 2 xHRSG -57/18 t/h;58/4 bara, 537/200degCSTG –38MWe

Syzran Power Station-2011, 200MWeCCPP, Russia, 2 x GTG –GE F6FA 80MWe, 2 x HRSG

1 x STG –40MWe

Tashkent CC Power Station-2012, 370 MWeCCPP, Uzbekistan, 1x GTG –GE F9FA 270 MWe, 1x HRSG

1 x STG –100 MWe
